Name: Centerlines_RadfordC_Project

Display Field: STREET_NAME

Type: Feature Layer

Geometry Type: esriGeometryPolyline

Description: <DIV STYLE="text-align:Left;"><DIV><DIV><P><SPAN>The Virginia Geographic Information Network (VGIN) has coordinated and manages the development of a consistent, seamless, statewide digital road centerline file with address, road name, and state route number attribution, as part of the Virginia Base Mapping Program (VBMP). The Road Centerline Program (RCL) leverages the Commonwealth's investment in the VBMP digital orthophotography and is focused on creating a single statewide, consistent digital road file. The RCL data layer is a dynamic dataset supported and maintained by Virginia's Local Governments, VDOT, and VGIN. VBMP RCL is extracted and provided back to local governments and state agencies in many geographic data sets every quarter. </SPAN></P></DIV></DIV></DIV>

Copyright Text: Virginia Geographic Information Network (VGIN), Virginia Department of Transportation (VDOT), Virginia local government GIS

Default Visibility: true

MaxRecordCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 0.0

Max Scale: 0.0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: false

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: 1.0872300334603637E7
YMin: 3564007.9199365675
XMax: 1.0895725536768883E7
YMax: 3583136.160551399
Spatial Reference: 102747  (2284)  LatestVCSWkid(0)

Drawing Info:

Renderer:
Simple Renderer:
Symbol:
Style: esriSLSSolid
Color: [104, 104, 104, 255]
Width: 1
Label: N/A
Description: N/A
Transparency: 0
Labeling Info:

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false

HasZ: false

HasM: false

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: null

Fields:

• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID )
• Shape ( type: esriFieldTypeGeometry, alias: Shape )
• RCL_ID ( type: esriFieldTypeDouble, alias: RCL_ID )
• LOCAL_ID ( type: esriFieldTypeDouble, alias: LOCAL_ID )
• VDOT_EDGE_ID ( type: esriFieldTypeDouble, alias: VDOT_EDGE_ID )
• MFIPS ( type: esriFieldTypeString, alias: MFIPS, length: 7 )
• GEOMETRY_EDIT_TYPE ( type: esriFieldTypeSmallInteger, alias: GEOMETRY_EDIT_TYPE )
• GEOMETRY_EFFECTIVE_DATE ( type: esriFieldTypeDate, alias: GEOMETRY_EFFECTIVE_DATE, length: 8 )
• GEOMETRY_SOURCE ( type: esriFieldTypeString, alias: GEOMETRY_SOURCE, length: 4 )
• GEOMETRY_EDIT_DATE ( type: esriFieldTypeDate, alias: GEOMETRY_EDIT_DATE, length: 8 )
• LEFT_FROM_ADDRESS ( type: esriFieldTypeInteger, alias: LEFT_FROM_ADDRESS )
• LEFT_TO_ADDRESS ( type: esriFieldTypeInteger, alias: LEFT_TO_ADDRESS )
• RIGHT_FROM_ADDRESS ( type: esriFieldTypeInteger, alias: RIGHT_FROM_ADDRESS )
• RIGHT_TO_ADDRESS ( type: esriFieldTypeInteger, alias: RIGHT_TO_ADDRESS )
• ADDRESS_RANGE_FORMAT ( type: esriFieldTypeString, alias: ADDRESS_RANGE_FORMAT, length: 1 )
• ADDRESS_RANGE_SOURCE ( type: esriFieldTypeString, alias: ADDRESS_RANGE_SOURCE, length: 4 )
• ADDRESS_RANGE_EDIT_DATE ( type: esriFieldTypeDate, alias: ADDRESS_RANGE_EDIT_DATE, length: 8 )
• STREET_PREMODIFIER ( type: esriFieldTypeString, alias: STREET_PREMODIFIER, length: 10 )
• STREET_PREFIX_DIRECTION ( type: esriFieldTypeString, alias: STREET_PREFIX_DIRECTION, length: 2 )
• STREET_NAME ( type: esriFieldTypeString, alias: STREET_NAME, length: 75 )
• STREET_SUFFIX ( type: esriFieldTypeString, alias: STREET_SUFFIX, length: 4 )
• STREET_SUFFIX_DIRECTION ( type: esriFieldTypeString, alias: STREET_SUFFIX_DIRECTION, length: 2 )
• STREET_POSTMODIFIER ( type: esriFieldTypeString, alias: STREET_POSTMODIFIER, length: 10 )
• STREET_NAME_FULL ( type: esriFieldTypeString, alias: STREET_NAME_FULL, length: 100 )
• STREET_NAME_SOURCE ( type: esriFieldTypeString, alias: STREET_NAME_SOURCE, length: 4 )
• STREET_NAME_EDIT_DATE ( type: esriFieldTypeDate, alias: STREET_NAME_EDIT_DATE, length: 8 )
• MTFCC ( type: esriFieldTypeString, alias: MTFCC, length: 10 )
• SEGMENT_TYPE ( type: esriFieldTypeSmallInteger, alias: SEGMENT_TYPE )
• LOCAL_SPEED_MPH ( type: esriFieldTypeSmallInteger, alias: LOCAL_SPEED_MPH )
• DUAL_CARRIAGEWAY ( type: esriFieldTypeString, alias: DUAL_CARRIAGEWAY, length: 1 )
• ONE_WAY ( type: esriFieldTypeString, alias: ONE_WAY, length: 2 )
• REVERSIBLE ( type: esriFieldTypeString, alias: REVERSIBLE, length: 1 )
• SEGMENT_EXISTS ( type: esriFieldTypeString, alias: SEGMENT_EXISTS, length: 1 )
• Shape_Length ( type: esriFieldTypeDouble, alias: Shape_Length )

Supported Operations:   Query   Query Attachments   Query Analytic   Generate Renderer   Return Updates
